| Rated water production capacity in 24 hrs | 485 litres / Day (at 80% RH and 30 Degree Celsius) 460 litres / Day (at avg 70% RH and 30 Degree Celsius) |
| Actual size (L*W*H) (cms) | 160*90*100 |
| Net Weight (kg) | 400 |
| Power rating (kW) | 7 kW (at 70 % RH and 30 Degree Celsius) |
| Refrigerant | R410A |
| Power supply | 380 Vac, 3 phase, 50 Hz |
| External storage tank capacity (litres) | 100 – 300, as required. |
| Sound level (dB) | < 70 |
| Air Purification | 10 Mircon – AI mesh supported HDPE fabric |
| Water Purification | 7 Stage filteration, including ozonizer, UV, UF membrane |
| Power efficiency | 0.27 kWh / Litres (at 80% RH and 30 Degree Celsius) 0.28 kWh / Litres (at 70% RH and 30 Degree Celsius) |
| Water output and power consumption is dependent on ambient conditions | |
Frequently Asked Questions
Which commercial and institutional sites is VayuJal Ultra designed for?
VayuJal Ultra is the first three-phase model in the range. It is rated at 485 litres a day at 80% humidity and 30 °C (460 litres at 70%), and can reach up to 580 litres a day in a favourable climate. It is built for high-demand sites with 50 to 300 users, such as restaurants, large offices and small industries, that want a reliable on-site alternative to tankers and packaged plastic-bottled water.
How much water can we claim in annual CSR or ESG reporting?
At its rated 485 litres a day, one unit can make about 177,000 litres a year (485 × 365). Output depends on ambient conditions, so use measured figures for disclosures.
What are the power and running-cost numbers for budgeting?
VayuJal Ultra uses 0.27 kWh per litre at 80% humidity and 0.28 kWh per litre at 70% humidity. At 485 litres a day that is about 131 kWh a day, or roughly ₹1.6 of electricity per litre at an example ₹6 per unit. Its rated power is 7 kW.
What electrical connection does it need?
It needs a 380 V, 3-phase, 50 Hz supply. Confirm that the site’s sanctioned load covers the 7 kW rating before ordering.
How do we plan storage and floor space?
Ultra uses an external storage tank of 100 to 300 litres, chosen to suit your demand pattern. The unit measures 160 × 90 × 100 cm, weighs 400 kg and has a sound level below 70 dB, so plan a firm, level location with airflow.
What purification does the water go through?
Air passes through a 10-micron HDPE fabric supported by aluminium mesh. The water then passes through 7-stage filtration that includes an ozonizer, UV and a UF membrane.
